Waste Tire/Plastic Pyrolysis Machine 10 Tons Used Tyre Retreading Into Oil Equipment Used Tire Vulcanizing Equipment for Truck Tire Cold Retreading/Curing Chamb

Basic Info.

Model NO.	jc-lh
Certification	CE, ISO
Condition	New
Customized	Customized
Automatic Grade	Automatic
Structure	Horizontal
Ass	Y
COM	Y
PLC	Y
Ship	Y
Transport Package	Wooden Case
Specification	40 HQ
Trademark	FINEYEAR
Origin	China
HS Code	84778000
Production Capacity	166 Per Year

Product Description

Motorcycle tyre tread cooling cutting production line:

Applica

tion: This machine is mainly used for cooling and collecting tyre tread or sidewall of bias tyre and radial tire after extruding.

Structure Features: This machine is mainly composed of take-up, contraction, constinuous weighting, marking, calendaring and sticking base system, cooling, speed set point setting, cutting, accelerated separation, water blow-off, inspection, spreading and spraying rubber cement, pick-up device etc., and designed according to the domestic and foreign advanced technologies, with speed regulation by AC frequency conversion, PLC control, entire line synchronization, no stretching for products.

Model	TMX
Line speed	5 ~ 25m/min
Take-up height	900mm
Width of production roller	650mm (design according to tread width)
Pick-up temperature	≤ 40ºC (Ambient temperature + 5ºC)
Cutter: Max. thickness of tread cutting	20mm
Max. cutting width	450mm
Range od cutting angle adjustment	35° ± 5°
Length tolerance of the cutting component	± 3
Cutting frequency	10 ~ 15 cuts/min
Pressure of compressed air	0.6 ~ 0.8 Mpa
Total motor power	23.3KW
Cooling water consumption	50 ~ 60 m3/h
Dimension (L*W*H)	28000*2000*2800mm
Weight	20000kg
